Helios 3" Square Adjustable

HED3 SERIES | Deep Regress Downlights

$103.5/PCS-$159/PCS

FEATURES SPECIFICATIONS

Small and powerful runs in this family of 3" aperture recessed downlight that offer up to 1700 delivered lumens. This mini downlight family is complete with high performance and an expansive range of options for optics, trim styles, trim configurations, beam spreads, housings, mounting, and more offering the flexibility your projects require. They are available in an expansive assortment of configurations to provide options for nearly every design requirement. It is a designer's favorite that delivers superior light in every application.

Architectural Friendly: Up to 50,000 unique combinations
Adjustable Ring: 360° rotation and a maximum 30° tilt angle
2 in 1 Dimming: 0-10V (Dim to 1%) and TRIAC in one package
COB LED: 4 Fixed CCT 90+ CRI or Dim to Warm 95+ CRI options
Beam Angle: 4 optics series with 15°~60° options
Trimmed, trimless with various shades options
New construction and remodel driver options for any site condition

Size	3inch
Light Source	LED Static/Dim To Warm
Lumens	Up To 1700LM
CCT	2700K, 3000K, 3500K, 4000K, Dim To Warm 3000K-2000K
CRI	90, 95
Product Type	Remodel, New Construction Housing
Listing	UL, cUL, Damp Rated
Dimming Protocol	0-10V, Triac
Trim Style	Adjustable, Fixed
Color	Black, White, Gold, Chrome
Mounting Type	Recessed
Voltage Rating	110-277VAC
Fixture Wattage	19W, 16W, 13W, 10W, 8W, 5W
