Vista 3" Square Mud-In Adjustable
VAD SERIES | Deep Regress Downlights
Consult For Pricing
FEATURES
SPECIFICATIONS
Small and powerful runs in this family of 3" aperture recessed downlight that offer up to 6000 delivered lumens. This mini downlight family is complete with high performance and an expansive range of options for optics, trim styles, trim configurations, beam spreads, housings, mounting, and more – offering the flexibility your projects
require. They are available in an expansive assortment of configurations to provide options for nearly every design requirement. It is a designer's favorite that delivers superior light in every application.
- New construction friendly: Low profile, less than 4" Height, ceiling
- Thickness 0.06"-0.94"
- Adjustable ring: 360° rotation and a maximum 25° tilt angle
- Very good glare control ugr < 13, shielding angle 50°
- Beam angle: 25°, 35°, 50° options
- Trimmed, trimless with various reflector finish
- New construction and remodel driver options for any site condition
- Wet location option
- With 1, 2 or 4 miniaturised single light heads in square arrangement
| Size | 3inch |
|---|---|
| Shape | Square |
| Light Source | LED - Static/Dim To Warm/Tunable White |
| Lumens | Up To 1500LM |
| CCT | 2700K, 3000K, 3500K, 4000K, Dim To Warm 1800K-3000K, Tunable White 2700K-6500K |
| CRI | 90, 97 |
| Product Type | Remodel, New Construction Housing |
| Listing | ETL, Damp Rated |
| Dimming Protocol | ON/OFF, Triac |
| Trim Style | Adjustable |
| Color | Black, White, Gold |
| Mounting Type | Recessed |
| Voltage Rating | 110-277VAC |
| Fixture Wattage | 15W |
